• Mesh covering increases air flow and ventilation
• Supports up to 7 fans for maximum air cooling
• Supports liquid cooling in the front of the case
• Supports high-end graphics cards up to 346mm/372mm (without front fan)
• Supports CPU coolers up to 160mm
Specifications are subject to change without notice.
Products and models may vary depending on your region.
Contact your local retailer for more information.
Large mesh area and minimalist design with “Airflow” as its core value,this series out-perform other cases at the same level.
TOP PANEL I/O
Ample USB ports, including HD audio and mic. with easy access to reset and rounded power button.
Supports up to 2×3.5” HDD and 3×2.5” HDD/SSD.
Dual Chamber Design keeps heat away from main chamber.
Supports high-end graphics card up to 372mm.
Supports 240mm liquid-cooling systems in front panel.
Top: 1 x 120mm Fan Rear : 1 x 120mm Fan (include) Side: 1 x 120mm Fan HDD: 1 x 120mm Fan
Top: 1 x 120mm Fan Rear : 1 x 120mm Fan (include) HDD: 1 x 120mm Fan
Model
Aero-300 Black
Case Type
Mid Tower
Steel Thickness
0.45mm
Motherboards
ATX、M-ATX
Case Dimensions (Overall)
198 x 460 x 415 mm (W x H x D, overall)
5.25” Drive Bay
1 (Exposed)
3.5” Drive Bay
2 (Internal)
2.5” Drive Bays
3(Internal)
Expansion Slots
7
GPU Clearance
346 mm / 372 mm(without front fan)
CPU Clearance
Support Max. Height of 160 mm For CPU
I/O Ports
2 x USB2.0 + 1 x USB3.0 + HD Audio.
Air Cooling
Front : 3 x 120mm Fan
Radiator Support
240mm x 120mm x 32mm
Net Weight
3.6Kg / 4.2Kg (Gross Weight)
Power Supply
ATX PSU (Optional)
EAN Code
4713105951738
Model
Aero-300 Black FAW
Case Type
Mid Tower
Steel Thickness
0.45mm
Motherboards
ATX、M-ATX（245 x 305mm）
Case Dimensions (Overall)
190 x 460 x 415 mm (W x H x D, overall)
5.25” Drive Bay
1 (Exposed)
3.5” Drive Bay
2 (Internal)
2.5” Drive Bays
3(Internal)
Expansion Slots
7
GPU Clearance
346 mm / 372 mm(without front fan)
CPU Clearance
Support Max. Height of 150 mm For CPU
I/O Ports
2 x USB2.0 + 1 x USB3.0 + HD Audio.
Air Cooling
Front : 3 x 120mm Fan
Radiator Support
240mm x 120mm x 32mm
Net Weight
3.6Kg / 4.2Kg (Gross Weight)
Power Supply
ATX PSU (Optional)
EAN Code
4713105951745
Download your user manual here.
