CS-109 White

MINI TOWER CASE

Designed with ventilation in mind, this high-performance mini tower case delivers superior air flow and ventilation for improved cooling performance. Convenient handle on top of the case allows for easy positioning and transport while adding a stylish and unique look. Supports liquid cooling in the front and rear of the case for maximum cooling efficiency.

  • Mesh front panel design allows for improved air flow and ventilation
  • Compact and versatile chassis design makes this case perfect for business, home, or gaming use
  • Convenient handle allows for easy positioning and transport
  • Comes equipped with steel or full tempered glass side panel
  • Supports liquid cooling in the front and rear of the case
  • Supports air cooling in the front and rear of the case
  • Supports CPU cooler up to 156mm for CS-109-G-WT-V1 and up to 158mm for CS-109-S-WT-V1
  • Supports high-end graphics cards up to 260mm (without front fan)

Specifications are subject to change without notice.
Products and models may vary depending on your region.
Contact your local retailer for more information.

Where To Buy
FEATURES SPECS

AVAILABLE IN TWO VERSIONS

CS-109-S-WT-v1

Fans Included
12cm Black Fan x 1

Side Panel
Steel

CS-109-G-WT-v1

Fans Included
12cm FRGB fan x 1

Side Panel
Tempered Glass

MESH FRONT PANEL DESIGN

Designed with ventilation in mind, this high-performance mini tower case comes with a mesh front panel to deliver superior airflow and ventilation.

COMPACT CHASSIS DESIGN

Featuring a compact and versatile chassis design, this mini tower case is perfect for business, home, or gaming use.

EASY TO HANDLE

Built with a convenient handle at the top of the case, allowing for easy positioning and transport while adding a stylish and unique look.

STEEL OR TEMPERED GLASS SIDE PANEL

Go for a more classic look with steel side panel or showcase the inside of your rig with full tempered glass side panel.

– CS-109-S-WT-v1: Steel side panel
– CS-109-G-WT-v1: Full tempered glass side panel

AIR COOLING

Supports air cooling in the front and rear of the case to enhance cooling performance.

  • Front: 120mm x 2 (Max.)
  • Rear: 120mm x 1 (Max.)

LIQUID COOLING

Supports liquid cooling in the front and rear of the case for maximum cooling efficiency.

  • Front: 120mm Radiator (Optional)
  • Rear: 120mm Radiator (Optional)

BUILT FOR HIGH PERFORMANCE

  • Supports Micro-ATX and Mini-ITX motherboards
  • Supports CPU coolers up to 156mm for CS-109-G-WT-V1 and up to 158mm for CS-109-S-WT-V1
  • Supports high-end graphics cards up to 260mm (without front fan)

CONVENIENT ACCESS TO YOUR MEDIA

Quick and easy access to USB 3.0 x 1, USB 2.0 x 2, HD audio and mic ports, and power & reset button.

STORAGE CAPABILITY

Supports up to 2 x 3.5” HDDs (2 x 3.5”), and 4 x 2.5” SSDs (4 x 2.5”).

PRODUCT GALLERY

CS-109-G-WT-v1
CS-109-S-WT-v1

SPECS

Model CS-109 White
Case Type Mini Tower
Color White
Body Material SPCC
Front Panel Material ABS
Steel Thickness 0.5mm
Motherboards Micro ATX/mini-ITX
Case Dimensions (Internal) 190 x 350 x 265 mm (W x H x D)
Case Dimensions (Overall) 195 x 385.4 x 314.8mm (W x H x D)
3.5” Drive Bays 2 Max. (2 x 3.5”)
2.5” Drive Bays 4 Max. (4 x 2.5”)
Expansion Slots 4
GPU Clearance Supports GPU up to 260mm (without front fan)
CPU Cooler Clearance Supports CPU cooler up to 156mm
Air Cooling Front: 120mm x 2 (Max.)
Rear: 120mm x 1 (Max.)
Liquid Cooling Front: 120mm Radiator (Optional)
Rear: 120mm Radiator (Optional)
I/O Ports USB3.0 x 1 | USB2.0 x 2 | HD Audio & Mic.
Internal Cable Management Depth 16.7mm
Power Supply ATX PSU (Optional)
EAN Code CS-109-S-WT-v1: 4711099472406 (120mm black fan x 1 included)
CS-109-G-WT-v1: 4711099472383 (120mm FRGB fan x 1 included)

CS-109 User Manual

Download
