Shard

RGB MID TOWER CASE

High-performance mid tower case with a stylish RGB LED design and acrylic in the front panel. Comes with a full acrylic side panel to showcase the inside of your rig. Air vents on the sides of the front panel provide superior air flow and ventilation.

Bring your case to life with 13 lighting modes: 6 RGB flow and 7 static color modes. Conveniently located LED control switch allows you to adjust your lighting effects to suit your unique style and mood.

  • Stylish RGB LED design with acrylic in the front panel
  • Access 13 preset lighting modes via conveniently located LED control button
  • Full acrylic side panel to showcase the inside of your rig
  • Air vents on the front panel provide superior air flow and circulation
  • Dual chamber design for improved ventilation
  • Supports CPU coolers up to 155mm
  • Supports high-end graphics cards up to 355mm

Specifications are subject to change without notice.
Products and models may vary depending on your region.
Contact your local retailer for more information.

FEATURES

BRING YOUR CASE TO LIFE

Unique RGB LED design on the front panel delivers a stylish look and feel. Bring your case to life with 13 preset lighting modes that can be readily controlled via LED control button.

6 RGB Flow Modes
7 Static Color Modes

IMPROVED AIR VENTILATION

Air vents on the sides of the front panel increase air flow and ventilation for superior cooling performance.

FLAUNT YOUR RIG

Comes equipped with a full acrylic side panel and acrylic in the front panel to properly showcase the inside of your rig.

DUAL CHAMBER DESIGN

Built with a dual chamber design to direct heat away from the main chamber for more effective all-around cooling.

AIR COOLING

Supports air cooling in the front, top, rear, and bottom of the case to enhance cooling performance.

Front: 120mm x 3 (Optional)
Top: 120mm x 2 (Optional)
Rear: 120mm x 1 (Includes 120mm Fan x 1)
VGA Fan: 120mm x 2 (Optional)

LIQUID COOLING

Supports liquid cooling in the front of the case for maximum efficiency cooling.

Front: 240mm Radiator (Optional)

COOLING FOR YOUR GRAPHICS CARD

Supports graphics card cooling: 2 x 120mm fans for superior VGA cooling.

BUILT FOR HIGH PERFORMANCE

Supports ATX, Micro-ATX, and Mini-ITX motherboards
Supports CPU coolers up to 155mm
Supports high-end graphics cards up to 355mm

CONVENIENT ACCESS TO YOUR MEDIA

Quick and easy access to LED control button, 1 x 3.0 USB, 2 x 2.0 USB, HD audio and mic ports, and power button.

STORAGE CAPABILITY

Supports up to 2 x 3.5” HDDs and 2 x 2.5” SSDs.

EASY MAINTENANCE

Removable dust filters on the top and bottom of the case for fast and convenient cleaning.

PRODUCT GALLERY

SPECS

ModelShard
Case TypeMid Tower
ColorBlack
Body Material SPCC
Front Panel Material ABS
Steel Thickness0.5mm
MotherboardsATX/micro-ATX/mini-ITX
Case Dimensions (Overall)194 x 444 x 423.5mm (W x H x D)
5.25” Drive Bays0
3.5” Drive Bay2
2.5” Drive Bay2
Expansion Slots7
GPU ClearanceSupports GPU up to 355mm (without front fan)
CPU Cooler ClearanceSupports CPU coolers up to 155mm
I/O PortsUSB3.0 x 1 | USB2.0 x 2 | HD Audio & Mic. | LED Control Button | Power Button
Liquid Cooling Front: 240mm Radiator (Optional)
Air Cooling SystemFront: 120mm x 3 (Optional)
Top: 120mm x 2 (Optional)
Rear: 120mm x 1 (Includes 120mm Fan) Supports
VGA Fan: 120mm x 2 (Optional)
Net Weight/Gross Weight3.37kg/4.23kg
Internal Cable Management Depth 24mm
Power SupplyATX PSU (Including cables, up to 200mm) (Optional)

USER MANUAL

Download your user manual here.
