DS230

MID TOWER CASE

• Stylish LED design with 10 lighting modes
• Passive Noise Canceling (PNC) Technology for maximum noise reduction
Supports liquid cooling in the front, top, and rear of the case
Supports air cooling in the front, top, and rear of the case
Supports high-end graphics cards up to 388mm / 413mm (without front fan)
Supports CPU coolers up to 170mm

Specifications are subject to change without notice.
Products and models may vary depending on your region.
Contact your local retailer for more information.

FEATURES

PNC
Passive Noise Cancelling

Noise dampening material are installed on front , top , side panels to ensure maximum reduction of noise induced by fans and other working components.

LED LIGHTING

Choice to select from 7LED colors & 3 Lighting modes.

PWM MODE

Integrated PWM fan control with LED effect.
Support up to 7 fans.
Base on the signal from motherboard.

SPACIOUS INTERIOR

Supports either 240mm or 280mm water cooling system on top panel.

Support 2 x 2.5″HDD/SSD

Supports high-end graphic card up to 388mm.

Supports either 280mm or 360mm water cooling system on front panel.

Support 1 x 2.5″HDD/SSD.

Support 2 x 3.5″HDD or 2 x 2.5” HDD/SSD on the HDD trays.

Support down-positioning PSU of up to 180mm.

PRODUCT GALLERY

VIDEOS

SPECS

ModelDS 230
Case TypeMid Tower
Steel Thickness 0.7mm
MotherboardsATX / micro ATX / mini-ITX
Case Dimensions (Overall)230 x 475 x 477.8mm (W x H x D, overall)
3.5″ Drive Bays 2 (Internal)
2.5” Drive Bays 3 (Internal)
Expansion Slots 7
GPU Clearance388 mm / 413 (without front fan)
CPU Clearance Support Max. Height of 170 mm For CPU
I/O Ports 2 x USB2.0 + 2 x USB3.0 + HD Audio & Mic.
Air Cooling Front : 3 x 120mm or 2 x 140mm (Optional)

Top: 2 x 120mm or 2 x 140mm (Optional)

Rear : 1 x 120mm fan (PWM fan Included)

Water Cooling System Front : 2 x 120mm or 3 x 120mm or 2 x 140mm (Optional)

Top: 2 x 120mm or 2 x 140mm (Optional)

Rear : 1 x 120mm (Optional)

Net Weight 8.2Kg / 9.7Kg (Gross Weight)
Power Supply ATX PSU (Optional)
EAN Code 4713105958331

DOWNLOADS

Download your user manual here.

How to ensure PWM hub is functioning correctly.
