LS-5200

MID TOWER CASE

Acrylic side panel window to showcase the inside of your rig
Mesh panels increase air flow and ventilation
Supports liquid cooling in the front, top, and rear of the case
Supports high-end graphics cards up to 346mm / 371mm (without front fan)
Supports CPU coolers up to 170mm
• Available in 2 color options: Black and White

Specifications are subject to change without notice.
Products and models may vary depending on your region.
Contact your local retailer for more information.

Categories: ,

FEATURES

AVAILABLE IN 2 COLOR COMBINATIONS

FAN SPEED CONTROL

Built-in two fan controller switches.
2 x USB2.0 + 1 x USB3.0 + HD Audio & Mic + Power button.

ULTRA-AIR COOLING

Huge air intake from the front panel .
Superb airflow system install up to 6 fans !

DUAL WATER-COOLING

Supports either 280mm or 360mm water cooling system on front panel.
Supports either 240mm or 280mm water cooling system on top panel.

SPACIOUS INTERIOR

Install either 4 x 2.5″ HDD/SSD and 3 x 3.5″ HDD on side space.
Install either 2 x 2.5″ HDD/SSD or 2 x 3.5″ HDD.

PRODUCT GALLERY

VIDEOS

SPECS

Model LS-5200
Case TypeMid Tower for water cooling
Steel Thickness 0.6mm
MotherboardsATX / micro ATX / mini-ITX
Case Dimensions (Overall)220 x 460 x 376.5 mm (W x H x D)
3.5" Drive Bays 3 + 2 (2.5/3.5 HDD Cage)
2.5” Drive Bays 2 + 4 (2.5/3.5 HDD Cage)
Expansion Slots 7
GPU Clearance346 mm / 371mm (without front fan)
CPU Clearance Support Max. Height of 170 mm For CPU
I/O Ports 2 x USB2.0 + 1 x USB3.0 + HD Audio & Mic.
Air Cooling

Front : 3 x 120mm or 2 x 140mm (Optional)

Top: 2 x 120mm or 2 x 140mm (Optional)

Rear : 1 x 120mm or 1 x 140mm fan (120mm Included)

Radiator Support

Front : 3 x 120mm or 2 x 140mm (Optional)

Top: 2 x 120mm or 2 x 140mm (Optional)

Rear : 1 x 120mm (Optional)

Net Weight 5.5Kg (GW:6.5Kg)
Power Supply ATX PSU (Optional)
EAN Code

4713105958317 – BLACK

4713105958324 – WHITE

DOWNLOADS

Download your user manual here.
