Mid tower case with an acrylic side panel window to showcase the inside of your rig. Comes equipped with a mesh covering on the front panel to increase air flow and ventilation.
• Acrylic side panel window to showcase the inside of your rig
• Mesh covering increases air flow and ventilation
• Supports air cooling in the front and rear of the case
• Supports high-end graphics cards up to 320mm
• Supports CPU coolers up to 150mm
• Available in 5 color options
Specifications are subject to change without notice.
Products and models may vary depending on your region.
Contact your local retailer for more information.
High-End Ultra Mid tower case for gamers and PC enthusiasts
Solidly constructed case with 0.5mm thickness
USB3.0 x 1 | HD Audio & Mic. | USB2.0 x 1 | Reset
Accessible : Three 5.25”
Internal : Four 3.5” and two 2.5”
Supports high-end CPU cooler up to 151.8mm
Supports high-end graphics card up to 350mm
Rear: 8cm Fan x 1 (Black Fan Included) 4713105958560 – Devil Red Edition 4713105958546 – Evil Black Edition 4713105958539 – Evil Blue Edition 4713105958553 – Evil Green Edition
Rear: 8cm Fan x 1 (Black Fan Included) 4713105958614 – Devil Red Edition 4713105958591 – Evil Black Edition 4713105958584 – Evil Blue Edition 4713105958607 – Evil Green Edition
Model
V3X Window
Case Type
Mid Tower
Color
Black
Steel Thickness
0.5mm
Motherboards
ATX/Micro ATX/Mini ITX
Case Dimensions (Overall)
176 x 412 x 412mm (W x H x D, overall)
5.25” Drive Bay
3 (Exposed)
3.5” FDD Drive Bays
1 (with 5.25″ adapter)
3.5” Drive Bay
2 (Internal) + 1 (Side Mount) + 1 (5.25″ Adapter)
2.5” Drive Bays
2 (Side Mount)
Expansion Slots
7
GPU Clearance
320mm
CPU Clearance
150mm
I/O Ports
USB2.0 x 2/Audio (HD) + Mic
Air Cooling
Front: 12cm Fan x 1 (Optional)
EAN Code
4713105958522 – Black Edition
Model
V3X Advance Window
Case Type
Mid Tower
Color
Black
Steel Thickness
0.5mm
Motherboards
ATX/Micro ATX/Mini ITX
Case Dimensions (Overall)
176 x 412 x 412mm (W x H x D, overall)
5.25” Drive Bay
3 (Exposed)
3.5” FDD Drive Bays
1 (with 5.25″ adapter)
3.5” Drive Bay
2 (Internal) + 1 (Side Mount) + 1 (5.25″ Adapter)
2.5” Drive Bays
2 (Side Mount)
Expansion Slots
7
GPU Clearance
320mm
CPU Clearance
150mm
I/O Ports
USB3.0 x 1/USB2.0 x 1/Audio (HD) + Mic
Air Cooling
Front: 12cm Fan x 1 (LED Fan Included)
EAN Code
4713105958577 – Black Edition
Download your user manual here.
