FEATURES
AVAILABLE IN 4 COLOR COMBINATIONS
TOP OF THE CLASS
Designed with “Airflow” as the core value , this series out-perform other cases at the same level.
Solidly built 0.5mm chassis with rounded top edges.
TOP OF THE CLASS
Designed with “Airflow” as the core value , this series out-perform other cases at the same level.
Solidly built 0.5mm chassis with rounded top edges.
DUAL WATER-COOLING
Both front panel and top panel support 240mm or 280mm watercooling systems.
Purposely designed top panel with a depth to mount watercooling system without interfering other componets.
DUAL WATER-COOLING
Both front panel and top panel support 240mm or 280mm watercooling systems.
Purposely designed top panel with a depth to mount watercooling system without interfering other componets.
DUST FILTER
Easy to clean PSU dust filter.
Magnetic top panel filter is easily removed for cleaning.
DUST FILTER
Easy to clean PSU dust filter.
Magnetic top panel filter is easily removed for cleaning.
HDD ALLOCATIONS
Support 2 x 3.5″HDD and 3 x 2.5″HDD/SSD or 5 x 2.5″HDD/SSD
SPECS
| Model |
Aero-800 |
| Case Type |
Mid Tower |
| Steel Thickness |
0.55mm |
| Motherboards |
ATX / micro ATX / mini-ITX |
| Case Dimensions (Overall) |
200 x 501 x 475.8mm (W x H x D, overall) |
| 5.25” Drive Bay |
2 (Exposed) |
| 3.5” Drive Bay |
2 (Internal , Compatible With 2.5″HDD/SSD) |
| 2.5” Drive Bays |
3 (Internal) |
| Expansion Slots |
7 |
| GPU Clearance |
390mm |
| CPU Clearance |
155mm |
| I/O Ports |
USB3.0 x 2 / USB2.0 x 2 / Audio(HD)+Mic |
| Air Cooling |
Front : 2 x 120mm Fans or 2 x 140 mm Fans (Included 1 x 120mm LED Fan)
Top : 2 x 120mm Fans (Optional)
Rear : 1 x 120mm fan ( Included 1 x 120mm Black Fan) |
| Radiator Support |
Front : 120 / 140 / 240 / 280mm Radiator Installation.(MAX. 40mm thickness)
Top : 120 / 240 mm Radiator Installation.(MAX. 32mm thickness)
Rear : 120mm Radiator Installation. |
| Net Weight |
6.15Kg (G.W 7.45 Kg) |
| Power Supply |
ATX PSU (Optional) |
| EAN Code |
4713105955538 – Black Edition
4713105955569 – Grey Edition
4713105955545 – White Edition
4713105955552 – Blue Edition |
| Model Variation |
Model Name |
| Standard |
Aero-800 Black
Aero-800 White
Aero-800 Blue
Aero-800 Gray |
| W / Card Reader |
Aero-800 Black – C
Aero-800 White – C
Aero-800 Blue – C
Aero-800 Gray – C |
| Model Variation |
Model Name |
| W / Black Bay Lever |
Aero-800 Black – B
Aero-800 White – B
Aero-800 Blue – B
Aero-800 Gray – B |
| W / Black Bay Lever+Card Reader |
Aero-800 Black – BC
Aero-800 White – BC
Aero-800 Blue – BC
Aero-800 Gray – BC |
DOWNLOADS
Download your user manual here.
