Beam

MID TOWER CASE

Designed with ventilation in mind, this high-performance mid tower case delivers superior air flow while allowing for viewing of your front LED fans. Full tempered glass side panel showcases the inside of your rig. Comes with two additional vertical expansion slots, allowing for vertical graphics card installation.

  • Front panel with air vents delivers superior air flow and ventilation while allowing for viewing of your front LED fans
  • Full tempered glass side panel showcases the inside of your rig
  • Two additional vertical expansion slots allow for vertical graphics card installation
  • Fan mounts on the PSU shroud support up to two 12cm fans for improved VGA cooling
  • Supports liquid cooling in the front, top, and rear of the case
  • Supports CPU cooler up to 160mm
  • Supports high-end graphics cards up to 343mm (without front radiator)

Specifications are subject to change without notice.
Products and models may vary depending on your region.
Contact your local retailer for more information.

Where To Buy
FEATURES SPECS VIDEOS

AVAILABLE IN TWO VERSIONS

Beam-G-BK-V1

Fans Included
12cm Black Fan x 1

Lighting Modes
N/A

Beam-G-BK-V2

Fans Included
12cm FRGB Fan x 4

Lighting Modes
Fixed RGB

EXPANSION SLOTS FOR VERTICAL GRAPHICS CARD INSTALLATION

Comes with two additional vertical expansion slots, allowing you to install your graphics card at a vertical position.

IMPROVED AIR VENTILATION

Stylish front panel design with built-in air vents delivers increased air flow and ventilation while allowing for viewing of your front LED fans.

FULL TEMPERED GLASS SIDE PANEL

Comes equipped with a full tempered glass side panel to showcase the inside of your rig and put your components on display.

COOLING FOR YOUR GRAPHICS CARD

Fan mounts on the PSU shroud support graphics card cooling :
2 x 120mm fans for superior VGA cooling.

AIR COOLING

Supports air cooling in the front, top, and rear of the case to enhance cooling performance.

  • Front: 120mm x 3 or 140mm x 3 (Max.)
  • Top: 120mm x 2 or 140mm x 2 (Max.)
  • Rear: 120mm x 1 (Max.)
  • PSU Shroud: 120mm x 2 (Max.)

LIQUID COOLING

Supports liquid cooling in the front, top, and rear of the case for maximum efficiency cooling.

  • Top: 120/240/280mm Radiator (Optional)
    (Fan + Radiator thickness <53mm)
  • Rear: 120mm Radiator (Optional)

DUAL CHAMBER DESIGN

Built with a dual chamber design to direct heat away from the main chamber for more effective all-around cooling.

BUILT FOR HIGH PERFORMANCE

  • Supports ATX, Micro-ATX, and Mini-ITX motherboards
  • Supports CPU coolers up to 160mm
  • Supports high-end graphics cards up to 343mm (without front radiator)

CONVENIENT ACCESS TO YOUR MEDIA

Quick and easy access to USB 3.0 x 1, USB 2.0 x 2, HD audio and mic ports, and power & reset button.

STORAGE CAPABILITY

Supports up to 2 x 3.5” HDDs (2 x 3.5”/2.5″) and 4 x 2.5” SSDs (2 x 2.5” and 2 x 2.5”/3.5”).

EASY MAINTENANCE

Removable dust filters for convenient cleaning and maintenance.

PRODUCT GALLERY

Beam-G-BK-V1
Beam-G-BK-V2

SPECS

Model Beam
Case Type Mini Tower
Color Black
Body Material SPCC
Front Panel Material ABS
Steel Thickness 0.5mm
Motherboards ATX/micro ATX/mini-ITX
Case Dimensions (Internal) 205 x 470 x 350mm (W x H x D)
Case Dimensions (Overall) 210 x 481.5 x 404mm (W x H x D)
3.5” Drive Bays 2 Max. (2 x 3.5”/2.5″)
2.5” Drive Bays 4 Max. (2 x 2.5” and 2 x 2.5”/3.5”)
Expansion Slots 7+2
GPU Clearance Supports GPU up to 343mm (without front radiator)
CPU Cooler Clearance Supports CPU cooler up to 160mm
Air Cooling Front: 120mm x 3 or 140mm x 3 (Max.)
Top: 120mm x 2 or 140mm x 2 (Max.)
Rear: 120mm x 1 (Max.)
PSU Shroud: 120mm x 2 (Max.)
Liquid Cooling Front: 120/240/280/360mm Radiator (Optional)
Top: 120/240/280mm Radiator
(Optional) ((Fan + Radiator) thickness <53mm)
Rear: 120mm Radiator (Optional)
I/O Ports USB3.0 x 1 | USB2.0 x 2 | HD Audio & Mic.
Internal Cable Management Depth 23.48mm
Power Supply ATX PSU (Including cables, up to 189mm) (Optional)
EAN Code Beam-G-BK-V1: 4711099471737 (Includes 1 x 12cm black fan)
Beam-G-BK-V2: 4711099471744 (Includes 4 x 12cm FRGB fan)
