CS-100

MINI TOWER CASE

• Features a stylish and compact design
Supports air cooling in the front, side, and rear of the case
Supports high-end graphics cards up to 325mm (without front fan)
Supports CPU coolers up to 145mm
Available in 2 color options: Black and White

Specifications are subject to change without notice.
Products and models may vary depending on your region.
Contact your local retailer for more information.

Categories: , , , , , , , , ,

FEATURES

AVAILABLE IN 2 COLOR COMBINATIONS

SMALL and MIGHTY

All black mini-tower designed for portable
desktop power with smaller footprint.

USB 2.0 x 2 | HD Audio and Mic | USB3.0 x 1

ADAPTS TO GAMER’S NEEDS

Install a 5.25″ ODD
Likewise, install two 3.5” HDD and 2.5” SSD.

Supports high-end graphics cards up to 325mm in length and up to 111m in width.
(300mm in length with front fan; 325mm in length without front fan)

PRODUCT GALLERY

SPECS

Model CS-100
Case Type Mini Tower
Steel Thickness 0.45mm
Motherboards Micro ATX / mini ITX
Case Dimensions (Overall) 191(W) x 356(H)x 373(D) mm
5.25” Drive Bay 1 (Exposed)
3.5” Drive Bay 2
2.5” Drive Bays 1
Expansion Slots 4
GPU Clearance 325mm (300mm with front fan installed)
CPU Clearance 145mm
I/O Ports 2 x USB2.0 / Audio(HD)+Mic
Air Cooling Front : 1 x 120mm fan (Optional)

Side : 1 x 120mm fan (Optional)

Rear : 1 x 80 mm fan ( Included 1 x 80mm Black fan)

Power Supply Standard ATX PS2 (Optional)
EAN Code 4713105955194
Model CS-100 Advance
Case Type Mini Tower
Steel Thickness 0.45mm
Motherboards Micro ATX / mini ITX
Case Dimensions (Overall) 191(W) x 356(H)x 373(D) mm
5.25” Drive Bay 1 (Exposed)
3.5” Drive Bay 2
2.5” Drive Bays 1
Expansion Slots 4
GPU Clearance 325mm (300mm with front fan installed)
CPU Clearance 145mm
I/O Ports USB3.0 x 1 / USB2.0 x 2 / Audio(HD)+Mic
Air Cooling Front: 12cm Fan x 1 (LED Fan Included)

Rear: 8cm Fan x 1 (Black Fan Included)

EAN Code 4713105955217

DOWNLOADS

Download your user manual here.
