CS-107

MINI TOWER CASE

Featuring a stylish and compact design, this highly-efficient mini tower case takes up less space than your typical case. Mesh front panel design delivers improved air flow and ventilation while allowing for viewing of your front LED fans. Comes equipped with full acrylic side panel to showcase the inside of your rig.

  • Compact chassis design makes this case perfect for office use
  • Mesh front panel design allows for improved air flow and ventilation
  • Full acrylic side panel showcases the inside of your rig
  • Supports liquid cooling in the front of the case
  • Supports air cooling in the front and rear of the case

Specifications are subject to change without notice.
Products and models may vary depending on your region.
Contact your local retailer for more information.

AVAILABLE IN TWO VERSIONS

CS-107-A-BK-V1

Fans Included
12cm black fan x 1

CS-107-A-BK-V2

Fans Included
12cm FRGB fans x 3

COMPACT CHASSIS DESIGN

Featuring a stylish and compact design, this corporate mini tower case is perfect for office use.

IMPROVED AIR VENTILATION

Mesh front panel design delivers increased air flow and ventilation while allowing for viewing of your front LED fan.

FULL ACRYLIC SIDE PANEL

Comes equipped with a full acrylic side panel to showcase the inside of your rig and put your components on display.

AIR COOLING

Supports air cooling in the front and rear of the case to enhance cooling performance.

  • Front: 120mm x 2 (Max.)
  • Rear: 120mm x 1 (Max.)

LIQUID COOLING

Supports liquid cooling in the front of the case for maximum efficiency cooling.

  • Front: 120/240 Radiator (Optional)
    (Radiator length <296mm)

BUILT FOR HIGH PERFORMANCE

  • Supports Micro-ATX and mini-ITX motherboards
  • Supports CPU coolers up to 157mm
  • Supports high-end graphics cards up to 286mm (without front radiator)

CONVENIENT ACCESS TO YOUR MEDIA

Quick and easy access to USB 3.0 x 1, USB 2.0 x 1, HD audio and mic ports, and power & reset button.

STORAGE CAPABILITY

Supports up to 1 x 3.5” HDDs and 2 x 2.5” SSDs.

PRODUCT GALLERY

CS-107-A-BK-V1
CS-107-A-BK-V2

SPECS

Model CS-107
Case Type Mini Tower
Color Black
Body Material SPCC
Front Panel Material ABS + Steel
Steel Thickness 0.45mm
Motherboards Micro ATX/mini-ITX
Case Dimensions (Internal) 183 x 350 x 290 mm (W x H x D)
Case Dimensions (Overall) 197.5 x 353 x 340.6mm (W x H x D)
3.5” Drive Bays 1 Max.
2.5” Drive Bays 2 Max.
Expansion Slots 4
GPU Clearance Supports GPU up to 286mm (without front radiator)
CPU Cooler Clearance Supports CPU cooler up to 157mm
Air Cooling Front: 120mm x 2 (Max.)
Rear: 120mm x 1 (Max.)
Liquid Cooling Front: 120/240mm Radiator (Optional)
(Radiator length <296mm)
I/O Ports USB3.0 x 1 | USB2.0 x 1 | HD Audio & Mic.
Internal Cable Management Depth 24.9mm
Power Supply ATX PSU (Including cables, up to 159mm) (Optional)
EAN Code CS-107-A-BK-v1: 4710562759372 (12cm black fan x 1 included)
CS-107-A-BK-v2: 4710562759389 (12cm FRGB fans x 3 included)

CS-107 User Manual
