V3X Window

MID TOWER CASE

Mid tower case with an acrylic side panel window to showcase the inside of your rig. Comes equipped with a mesh covering on the front panel to increase air flow and ventilation.

Acrylic side panel window to showcase the inside of your rig
Mesh covering increases air flow and ventilation
Supports air cooling in the front and rear of the case
Supports high-end graphics cards up to 320mm
Supports CPU coolers up to 150mm
Available in 5 color options

Specifications are subject to change without notice.
Products and models may vary depending on your region.
Contact your local retailer for more information.

FEATURES

AVAILABLE IN 5 COLOR COMBINATIONS

CASE OVERVIEW

High-End Ultra Mid tower case for gamers and PC enthusiasts
Solidly constructed case with 0.5mm thickness

USB3.0 x 1 | HD Audio & Mic. | USB2.0 x 1 | Reset

SPACIOUS INTERIOR

Accessible : Three 5.25”
Internal : Four 3.5” and two 2.5”

Supports high-end CPU cooler up to 151.8mm

Supports high-end graphics card up to 350mm

PRODUCT GALLERY

SPECS

Model V3X Window
Case Type Mid Tower
Color Black
Steel Thickness 0.5mm
Motherboards ATX/Micro ATX/Mini ITX
Case Dimensions (Overall) 176 x 412 x 412mm (W x H x D, overall)
5.25” Drive Bay 3 (Exposed)
3.5” FDD Drive Bays 1 (with 5.25″ adapter)
3.5” Drive Bay 2 (Internal) + 1 (Side Mount) + 1 (5.25″ Adapter)
2.5” Drive Bays 2 (Side Mount)
Expansion Slots 7
GPU Clearance 320mm
CPU Clearance 150mm
I/O Ports USB2.0 x 2/Audio (HD) + Mic
Air Cooling Front: 12cm Fan x 1 (Optional)

Rear: 8cm Fan x 1 (Black Fan Included)

EAN Code 4713105958522 – Black Edition

4713105958560 – Devil Red Edition

4713105958546 – Evil Black Edition

4713105958539 – Evil Blue Edition

4713105958553 – Evil Green Edition

Model V3X Advance Window
Case Type Mid Tower
Color Black
Steel Thickness 0.5mm
Motherboards ATX/Micro ATX/Mini ITX
Case Dimensions (Overall) 176 x 412 x 412mm (W x H x D, overall)
5.25” Drive Bay 3 (Exposed)
3.5” FDD Drive Bays 1 (with 5.25″ adapter)
3.5” Drive Bay 2 (Internal) + 1 (Side Mount) + 1 (5.25″ Adapter)
2.5” Drive Bays 2 (Side Mount)
Expansion Slots 7
GPU Clearance 320mm
CPU Clearance 150mm
I/O Ports USB3.0 x 1/USB2.0 x 1/Audio (HD) + Mic
Air Cooling Front: 12cm Fan x 1 (LED Fan Included)

Rear: 8cm Fan x 1 (Black Fan Included)

EAN Code 4713105958577 – Black Edition

4713105958614 – Devil Red Edition

4713105958591 – Evil Black Edition

4713105958584 – Evil Blue Edition

4713105958607 – Evil Green Edition

DOWNLOADS

Download your user manual here.
