Duo 20

20CM RGB PC FAN

200mm fan with 6-Pin connector featuring a stylish Double Ring RGB LED Lighting design. Access 16.8 million colors using compatible Addressable RGB motherboards including ASUS Aura Sync, MSI Mystic Light Sync, and Gigabyte RGB Fusion. Requires Addressable RGB motherboard or hub (H66F / H106C). Comes with a 6-Pin adapter cable to connect your fan with compatible Addressable RGB motherboards.

  • Access 16.8 million colors using compatible Addressable RGB motherboards
  • Comes with a 6-Pin Addressable RGB adapter cable
  • Double Ring RGB LED Lighting design adds extra flair to your rig
  • Curved fan blades for maximum cooling performance
  • Anti-vibration pads absorb and dampen vibrations caused by fan rotation
  • 34 LEDs ensure complete evenness and uniformity in color and brightness

Specifications are subject to change without notice.
Products and models may vary depending on your region.
Contact your local retailer for more information.

Categories: , , , , ,

FEATURES

DOUBLE RING RGB LED LIGHTING

Double RGB LED rings around the fan and circling the center of the fan to deliver a stylish and vibrant lighting experience while offering a truly unique way to keep your system cool, in more ways than one.

ADDRESSABLE RGB COMPATIBLE

Access 16.8 million colors using compatible Addressable RGB motherboards including ASUS Aura Sync, MSI Mystic Light Sync, and Gigabyte RGB Fusion.

Requires Addressable RGB motherboard or hub (H66F / H106C).

ADDRESSABLE RGB ADAPTER CABLE INCLUDED

Comes with a 6-Pin adapter cable to connect your fan with compatible Addressable RGB motherboards.

H66F HUB FOR PWM CONTROL FUNCTIONS

Compatible with PWM control functions for optimized fan speed to maximize cooling efficiency and minimize noise.

(Requires H66F Hub – sold separately)

For more information, refer to our PWM Compatibility Guide.

4-Pin Connector

6-Pin Fan Connector

ARGB MB Connector
(For all other ARGB MBs such as ASUS, MSI, etc.)

ARGB MB Connector
(Gigabyte RGB Fusion)

CURVED FAN BLADES

Curved fan blades effectively direct airflow to increase air pressure and reduce air resistance for maximum cooling performance.

ANTI-VIBRATION PADS

Anti-vibration pads absorb and dampen vibrations caused by fan rotation.

COMES WITH 6-PIN CONNECTOR



PRODUCT GALLERY

VIDEOS

SPECS

Model Duo 20 ARGB 6-pin
Fan Dimensions (L x W x H) 200 x 200 x 25mm
Fan Speed 700 rpm
Connector Type Fan: 6-Pin

Adapter Cable: 6-Pin

Fan Starting Voltage 6V
Fan Rated Voltage 12 V
Fan Rated Current 0.2 A
Power Consumption 2.4 W
Air Pressure 1.79 mmH2O
Air Flow 62.1 CFM
Fan Noise Level 18.3 dBA
Bearing Type Hydraulic Bearing
MTBF 60000 hrs.
EAN Code 4710562752601
